Panel Dimensions |
|
Standard Sizes: |
2440 to 3350 mm in length |
Thickness |
12, 16, 19 & 25 mm |
Density |
0.845 to 1.00 gm/cm3 |
Warranty |
2 years |
Custom colors & grades can be produced on demand |
TECHNICAL SPECIFICATIONS | |||||
Dimensions | BIS Requirements | Observation Values | |||
1 | Length |
|
2442mm | ||
2 | Width |
|
1222mm | ||
3 | Thickness | 25mm 24.90mm | |||
4 | Squareness | 2mm/1000mm | 0.95mm | ||
5 | Edge Straightness | 2mm/1000mm | 0.50mm | ||
6 | Workmanship & finish | Clause Satisfactory | |||
Physical Properties | |||||
7 | Density | 0.95 gm/cm² | 0.96 gm/cm² | ||
8 | Moisture Content | 5-15% | 7.90% | ||
9 | Bond Quatlity Test Boiling - Drying @ 60+_2°c 4 Hrs. - 20 Hrs. Three Cycles |
a) No Visible delamination in glue line and plywood face b) No forcible separation and fibre should be adhered between plies |
Satisfactory Satisfactory |
||
10 | Breaking Strength 250 x 50 x Thickness(mm) |
Along - 550kgf Across - 400kgf |
729kgf 493kgf |
||
11 | Static Bending Strength Along the grain M.O.E. Across the grain M.O.E. Along the grain M.O.R. Across the grain M.O.R. |
Avg. -7500N/mm² Ind. - 6700N/mm² Avg. - 4000N/mm² Ind. - 3600N/mm² Avg. - 50 Ind. - 45 Avg. - 30 Ind. - 27 |
8544.35N/mm² 7353.42N/mm² 5973.94N/mm² 4120.30N/mm² 70.224N/mm² 48.29N/mm² 58.782N/mm² 42.30N/mm² |
||
12 | Tensile Strength | Along - 55 MPa Across - 50 MPa |
68.32 MPa 57.29 MPa |
